Generating Private Key And Ssl Signed Certificate

Overview

Generating a keyring file with a self-signed or third-party certificate. To set up SSL on your server, you need a key ring containing a server certificate from an Internet certificate authority. SSL port configuration. The SSL protocol always provides an encrypted, integrity-checked, communications channel and authenticated server identity.

This article shows you how to create a self-signed root certificate and generate client certificates using PowerShell on Windows 10 or Windows Server 2016. If you are looking for different certificate instructions. Export the self-signed root certificate and private key to store it (optional). To obtain the SSL certificate, complete the steps: Set the OpenSSL configuration environment variable (optional). Generate a key file. Create a Certificate Signing Request (CSR). Send the CSR to a certificate authority (CA) to obtain an SSL certificate. (To generate an encrypted key/certificate pair, refer to Generating an Encrypted Private Key and Self-Signed Public Certificate.) General Information. When operating in a FIPS-approved mode, PKI key/certificates must be between 1024- bits and 4096-bits, inclusive. The supported cipher combinations allowed for SSL negotiation are limited to. Using Microsoft IIS to generate CSR and Private Key. A CSR in Microsoft IIS 7; 2. Back Up Private Key; 3. Convert to RSA Private Key Format; You can also use Microsoft IIS to generate a Private Key and CSR. How to generate a CSR in Microsoft IIS 7. Look for a folder called REQUEST or 'Certificate Enrollment Request Certificates.

The following is an extremely simplified view of how SSL is implemented and what part the certificate plays in the entire process.

Normal web traffic is sent unencrypted over the Internet. That is, anyone with access to the right tools can snoop all of that traffic. Obviously, this can lead to problems, especially where security and privacy is necessary, such as in credit card data and bank transactions. The Secure Socket Layer is used to encrypt the data stream between the web server and the web client (the browser).

SSL makes use of what is known as asymmetric cryptography, commonly referred to as public key cryptography (PKI). With public key cryptography, two keys are created, one public, one private. Anything encrypted with either key can only be decrypted with its corresponding key. Thus if a message or data stream were encrypted with the server's private key, it can be decrypted only using its corresponding public key, ensuring that the data only could have come from the server.

If SSL utilizes public key cryptography to encrypt the data stream traveling over the Internet, why is a certificate necessary? The technical answer to that question is that a certificate is not really necessary - the data is secure and cannot easily be decrypted by a third party. However, certificates do serve a crucial role in the communication process. The certificate, signed by a trusted Certificate Authority (CA), ensures that the certificate holder is really who he claims to be. Without a trusted signed certificate, your data may be encrypted, however, the party you are communicating with may not be whom you think. Without certificates, impersonation attacks would be much more common.

Generating Private Key And Ssl Signed Certificate

Step 1: Generate a Private Key

The openssl toolkit is used to generate an RSA Private Key and CSR (Certificate Signing Request). It can also be used to generate self-signed certificates which can be used for testing purposes or internal usage.

The first step is to create your RSA Private Key. This key is a 1024 bit RSA key which is encrypted using Triple-DES and stored in a PEM format so that it is readable as ASCII text.

Step 2: Generate a CSR (Certificate Signing Request)

Once the private key is generated a Certificate Signing Request can be generated. The CSR is then used in one of two ways. Ideally, the CSR will be sent to a Certificate Authority, such as Thawte or Verisign who will verify the identity of the requestor and issue a signed certificate. The second option is to self-sign the CSR, which will be demonstrated in the next section.

During the generation of the CSR, you will be prompted for several pieces of information. These are the X.509 attributes of the certificate. One of the prompts will be for 'Common Name (e.g., YOUR name)'. It is important that this field be filled in with the fully qualified domain name of the server to be protected by SSL. If the website to be protected will be https://public.example.com, then enter public.example.com at this prompt. The command to generate the CSR is as follows:

Step 3: Remove Passphrase from Key

One unfortunate side-effect of the pass-phrased private key is that Apache will ask for the pass-phrase each time the web server is started. Obviously this is not necessarily convenient as someone will not always be around to type in the pass-phrase, such as after a reboot or crash. mod_ssl includes the ability to use an external program in place of the built-in pass-phrase dialog, however, this is not necessarily the most secure option either. It is possible to remove the Triple-DES encryption from the key, thereby no longer needing to type in a pass-phrase. If the private key is no longer encrypted, it is critical that this file only be readable by the root user! If your system is ever compromised and a third party obtains your unencrypted private key, the corresponding certificate will need to be revoked. With that being said, use the following command to remove the pass-phrase from the key:

The newly created server.key file has no more passphrase in it.

Step 4: Generating a Self-Signed Certificate

At this point you will need to generate a self-signed certificate because you either don't plan on having your certificate signed by a CA, or you wish to test your new SSL implementation while the CA is signing your certificate. This temporary certificate will generate an error in the client browser to the effect that the signing certificate authority is unknown and not trusted.

To generate a temporary certificate which is good for 365 days, issue the following command:

Step 5: Installing the Private Key and Certificate

Self Signed Ssl Certificate Error

When Apache with mod_ssl is installed, it creates several directories in the Apache config directory. The location of this directory will differ depending on how Apache was compiled.

Certificate

Step 6: Configuring SSL Enabled Virtual Hosts on Apache

Step 7: Restart Apache and Test
